A Mib é a PARKS-SENSOR-MIB.mib


 pkSensorTable .1.3.6.1.4.1.3893.1.32.1

     pkSensorEntry .1.3.6.1.4.1.3893.1.32.1.1

 pkSensorIndex .1.3.6.1.4.1.3893.1.32.1.1.1.X
pkSensorLabel .1.3.6.1.4.1.3893.1.32.1.1.2.X
 pkSensorValue .1.3.6.1.4.1.3893.1.32.1.1.3.X
 - Most recent value. To correctly interpret this  value the related pkSensorValueType and pkSensorValueScale objects must also be examined.
 pkSensorValueScale .1.3.6.1.4.1.3893.1.32.1.1.4.X
 -  Power of 10 scaling factor associated with the Sensor value.
 pkSensorValueType .1.3.6.1.4.1.3893.1.32.1.1.5.X
 Type of data units associated with the Sensor
value. Valid values are:
other(1) - a type other than those listed
unknown(2) - Unknown, arbitrary or relative
percentage(3) - Percentage
celsius(4) - temperature
 truthvalue(5) - {true(1), false(2) }
 pkSensorStatus .1.3.6.1.4.1.3893.1.32.1.1.6.X
 Sensor Operational Status:
ok(1) - Agent can obtain sensor value and it is ok.
alarm(2) - Agent can obtain sensor value and it is anomalous.
 unavailable(3) - Agent cannot obtain sensor value.

 pkSensorValueTypeDisplay .1.3.6.1.4.1.3893.1.32.1.1.7.X
  The textual description of the data units to the related pkSensorValueType.
 pkSensorValueTimeStamp .1.3.6.1.4.1.3893.1.32.1.1.8.X
 The value of sysUpTime at the time the status and/or value of this sensor was last obtained by the agent.
 pkSensorValueUpdateRate .1.3.6.1.4.1.3893.1.32.1.1.9.X
  An indication of the frequency that the agent updates the related pkSensorValueValue, in milliseconds.
The value zero indicates:
-the sensor value is updated on demand (e.g., when polled by the agent for a get-request)
-the sensor value is updated when the sensor value changes
 -the agent does not know the update rate
